Reverse lights not working !!
Topic Started: 12 Mar 2012, 11:08 AM (187 Views)
Fat_Mole
Member Avatar
Tidy Regular
On my seat toaster the reverse lights stopped working a while ago and Ive changed the switch also checked the fuses also tested the connection the the rear lights all the power is getting using a multimeter but still no lights :( I've replaced the switch with the old one and pressed it while out of the gear box and the same with the new switch!! Any ideas?

Cheers
Offline Profile Quote Post Goto Top

damski
Member Avatar
Mi culo sobre el fuego.
Did you try a new bulb?
Offline Profile Quote Post Goto Top

Fat_Mole
Member Avatar
Tidy Regular
I've swaped bulbs around and no joy really but admittingly I only done that with the old switch in
Offline Profile Quote Post Goto Top

Fat_Mole
Member Avatar
Tidy Regular
Swapped the bulbs about still nothing!! Any other ideas?
Offline Profile Quote Post Goto Top

Mike_M
Member Avatar
TIDY WEB MASTER!
Broken wires to the switch. Happened on my Mk4 Golf. The wires broke close to the switch plug. Stripped and cut back a cm and reconnected everything and it was fine again
Offline Profile Quote Post Goto Top

Fat_Mole
Member Avatar
Tidy Regular
How far up should I go really I've had a look at the pins on the switch but they don't seem bad. But I've got some more plugs for it to try on the weekend.
Offline Profile Quote Post Goto Top

Mike_M
Member Avatar
TIDY WEB MASTER!
Pins would be fine the vibrations etc break the wire a couple of cm from pins internally.

Test by putting the car in reverse with ignition turned and engine not running (get a mirror or friend to check rear lights while you work in the front) .........unplug the reverse switch and with another piece of wire, insert into plug to join the 2 pins (acts as if the switch is constantly on) jig, bend etc the wires and see if the reverse light randomly turn on and off.

If so the wires are broken and some cutting back and rejoining will be required.
Offline Profile Quote Post Goto Top

Fat_Mole
Member Avatar
Tidy Regular
Well sorted it!! Rewired the switch and by passed the fuse because the fuse plugy thing wasn't there so was the only option really! Well problem resolved now :) hopefully!!
Offline Profile Quote Post Goto Top
